Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
5ACLS-3R
5ACLS-3R is an Eaton Bussmann series ACLS fuse designed for motor start applications with Class R current-limiting protection. 5ACLS-3R delivers reliable overcurrent protection in industrial power distribution systems requiring high interrupt capacity and fast response times. This single barrel ferrule-mounted fuse combines Ampgard technology with Class R specifications to safeguard equipment and circuits from fault conditions while maintaining system integrity.
- Amperage Rating: 100A
- Voltage Rating: 4.8 kV
- Interrupt Rating: 50 kAIC
- Fuse Type: Class R
- Series: ACLS
- Mounting: Single Barrel Ferrule
- Application: Motor Start
- Technology: Ampgard Current Limiting
Specifications
- Part Number: 5ACLS-3R
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : CLS
- Type : ACLS
- Voltage : 5080
- Amperage : 100
- AIC rating : [email protected]
- Connection : Ferrule
- Diameter : 3
- Class Rating : R
- Barrels : 1
Product Data
- UPC : 051712527859
- GTIN : 00786670221340
- Country of Origin : Dominican Republic
- Dimensions : 15.9 in x 4.2 in x 3 in (Length/Depth x Height x Width)
- Weight : 9
- Certification : ANSI C37.46, UL Recognized Guide MSSS2 File E60757
