Product Info
- Manufacturer:Socomec
- Sub-Category:Fuse Part And Accessory
Description
57050012
57050012 is a modular fuse holder with blown fuse indicator for Class CC fuses. It is DIN rail mounted and designed for industrial applications.RM CC series fuse holders accept UL Class CC fuses up to 30A and 600 VAC, featuring LED indication and pressure plate terminals for 18-8 AWG copper wire.Key Specifications
- Part Number: 57050012
- Manufacturer: Socomec
- Amperage: 30 A
- Voltage: 600 V
- Poles: 2
- Fuseclass: Class CC
- Wire: 18-8 AWG copper only
- Connection: Pressure plate
- Mounting: 35mm DIN rail
- AIC Rating: 200 kA
Specifications
- Part Number: 57050012
- Manufacturer : Socomec
- Brand : Socomec
- Category : Fuse
- Item Subcategory : Fuse Part And Accessory
- Section : Fuse Holders
- Voltage : 600 V
- Amperage : 30 A
- Poles : 2
- AIC rating : 200 kA
- Connection : Pressure plate
- Fuse Class : Class CC
- Diameter : 37
- Wire : 18-8 AWG copper only
- Barrels : 1
- Velocity : High Speed
- Mounting : 35mm DIN rail
