Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage
Description
55GDMSJD20E
55GDMSJD20E is a medium voltage specialty fuse manufactured by Eaton Bussmann Electrical Division, designed for industrial power distribution and circuit protection applications requiring high reliability at elevated voltages. This E-Rated DIN cartridge fuse delivers dependable performance in demanding electrical systems where medium voltage protection is critical. 55GDMSJD20E combines ceramic construction with a striker pin indicator mechanism to provide both protection and operational visibility. The fuse features slow-blow response characteristics, making it suitable for applications with inrush currents while maintaining fast response to sustained fault conditions. Its non-standard cartridge design integrates seamlessly into specialized medium voltage equipment and switchgear assemblies.
- Amperage Rating: 20A
- Voltage Rating: 5.5 kV AC
- Interrupt Rating: 65 kAIC
- Fuse Type: Cartridge, Ceramic
- Response Time: Slow Blow
- Indicator: Striker Pin with Indicator
- Resistance: 24.6 ohms
- Watt Losses: 11 W
- Series: E-Rated DIN
- Termination Style: Cartridge (Non-Standard)
Specifications
- Part Number: 55GDMSJD20E
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage
- Family : GDMSJD Series
- Type : GDMSJD
- Voltage : 5500
- Amperage : 20
- Diameter : 2
- Class Rating : E
- Clip Center : 17.4
Product Data
- Weight : 5
