Product Info
- Manufacturer:Siemens
Description
49SDLBU
49SDLBU is a Siemens 22mm multiuse LED pilot light designed for 24 to 240 V AC/DC applications with a NEMA 1 enclosure.This pilot light features a red LED lamp with a screw-type terminal connection suitable for solid and stranded conductors from 18 to 12 AWG. It supports mounting with a rear mounting type and a mounting diameter of 30.5 mm. The device is finger-safe and rated for ambient operating temperatures from -20 to 60 degrees Celsius. It is certified with ISO 9001 and designed for reliable operation with a typical operating period of 100,000 hours. The unit is made in Germany and complies with NEMA 1 environmental ratings.
- Key Specifications
- Voltage Rating: 24 to 240 V AC/DC
- LED Lamp Color: Red
- Mounting Type: Rear
- Mounting Diameter: 30.5 mm
- Wire Connection: Screw-type terminals
- Wire Size: 18-12 AWG solid and stranded copper
- Operating Temperature: -20 to 60 °C
- Environmental Rating: NEMA 1
- Certification: ISO 9001
- Typical Operating Life: 100,000 hours
- Finger-safe Design
- Country of Origin: Germany
Specifications
- Part Number: 49SDLBU
- Brand : Siemens
Product Data
- Weight : 0.3
