Product Info
- Manufacturer:Siemens
- Sub-Category:Medium Voltage
Description
48FM12X-4
48FM12X-4 is a Siemens FM series current-limiting fuse designed for motor starting applications. This fuse is rated for 4.8kV and 12A, providing reliable protection in medium voltage systems. The Siemens 48FM12X-4 is a totally enclosed, current-limiting fuse constructed with silver elements surrounded by inorganic sand, all enclosed in a strong polyester base insulating tube. It features silver-plated copper ferrules for low resistance connections and a mechanical indicator that projects from the lower end when the fuse element melts. This fuse is suitable for motor starting and other high-demand applications requiring robust protection.
- Manufacturer: Siemens
- Part Number: 48FM12X-4
- Series: FM
- Application: Motor Starting
- Rated Voltage: 4.8kV
- Rated Current: 12A
- Interrupting Rating: 80,000A RMS Asymmetrical
- Mounting Type: Ferrule Connection
- Construction: Silver elements, inorganic sand, polyester base tube
- Indicator: Mechanical type
- Connection: Silver-plated copper ferrules
Specifications
- Part Number: 48FM12X-4
- Manufacturer : Siemens
- Brand : Allis Chalmers
- Category : Fuse
- Item Subcategory : Medium Voltage
- Type : FM
- Voltage : 4800
- Amperage : 12
- Connection : Ferrule
- Diameter : 3
- Class Rating : R
- Barrels : 1
- Clip Center : 12
Product Data
- Weight : 9
