Product Info
- Manufacturer:S&C Electric
- Sub-Category:Medium Voltage
Description
484200R3
484200R3 is an S&C Electric medium voltage power fuse rated 200 amperes at 34.5kV with slow-speed operation for distribution and substation applications. This SMD-2C class fuse delivers fast, positive fault interruption through high-speed arc elongation in a solid-material-lined bore and efficient deionizing action from thermally generated gases. The fuse is designed for close fusing to achieve maximum protection and optimum coordination in medium voltage systems. Key Specifications
- Part Number: 484200R3
- Manufacturer: S&C Electric
- Voltage Rating: 34.5kV nominal
- Amperage Rating: 200E continuous
- Fuse Type: SMD-2C
- Speed Curve: Slow
- Interrupting Rating: 33.5kA at 34.5kV
- BIL: 150kV
- Maximum Symmetrical Interrupting: 6,250 amperes RMS symmetrical
- Arc-Extinguishing Medium: Solid-material-lined bore with deionizing gas generation
Specifications
- Part Number: 484200R3
- Manufacturer : S&C Electric
- Brand : S&C Electric
- Category : Fuse
- Item Subcategory : Medium Voltage
- Section : Fuse Link
- Type : SMD-2C
- Voltage : 34500
- Amperage : 200
- AIC rating : [email protected]
- Class Rating : SMD-2C
- Velocity : Slow
Product Data
- Weight : 10
