Product Info
- Manufacturer:S&C Electric
- Sub-Category:Medium Voltage
Description
464050R3
464050R3 is an S&C Electric medium voltage power fuse designed for outdoor distribution and substation applications. This SMD-2C class fuse unit provides reliable fault interruption and protection coordination in medium voltage power systems.Technical Description: The 464050R3 operates at a nominal voltage of 34.5 kV with a maximum ampere rating of 50 amperes. It features a 50E speed rating for fast, positive fault interruption achieved through high-speed arc elongation in the solid-material-lined bore and efficient deionizing action. The fuse has an interrupting rating of 33.5 kA at 34.5 kV, providing robust protection against system faults. This fuse unit is part of S&C Electric's SMD power fuse family, which is manufactured in accordance with ISO 9001:2000 quality standards.Key Specifications
- Part Number: 464050R3
- Manufacturer: S&C Electric
- Fuse Class: SMD-2C
- Voltage Rating: 34.5 kV nominal, 38 kV maximum
- Ampere Rating: 50 A
- Speed: 50E (Fast)
- Interrupting Rating: 33.5 kA at 34.5 kV
- Application: Outdoor distribution and substation protection
- Quality Standard: ISO 9001:2000
Specifications
- Part Number: 464050R3
- Manufacturer : S&C Electric
- Brand : S&C Electric
- Category : Fuse
- Item Subcategory : Medium Voltage
- Type : SMD-2C
- Voltage : 34500
- Amperage : 50
- AIC rating : [email protected]
- Class Rating : SMD-2C
- Velocity : Standard
Product Data
- Weight : 15
