Description
45EG10AJA
45EG10AJA is a Furnas Class 45 definite purpose contactor designed for reliable motor control applications. This 1-pole contactor features a 24VAC coil and is rated for 30A maximum load current at up to 600VAC, making it suitable for compressor motors and electric heating loads. The 45EG10AJA is part of the Model G series, offering screw terminal termination and a jumper bar for easy installation. It is engineered for 50/60 Hz frequency operation and features silver cadmium oxide contacts for durability and consistent performance.
- Part Number: 45EG10AJA
- Manufacturer: Furnas
- Series: Class 45, Model G
- Type: Definite Purpose Contactor
- Poles: 1 Pole
- Maximum Load Current: 30A
- Operating Voltage: 600VAC
- Coil Voltage: 24VAC
- Frequency: 50/60 Hz
- Termination: Screw Terminal
- Features: Jumper Bar, Auxiliary Contacts
- Mounting Type: Panel Mount
Specifications
- Part Number: 45EG10AJA
- Manufacturer : Furnas
- Brand : Furnas
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 45
- Type : 45EG
- Voltage : 600
- Amperage : 30
- Phase : 1
- Poles : 1
- Coil Voltage Maximum : 24
Product Data
- UPC : 783087145221
- GTIN : 00783087145221
- Country of Origin : China
- Dimensions : 3.15 x 2.756 x 1.969 inch
- Weight : 0.58
