Description
42EF35AH
42EF35AH is a Siemens Furnas Class 42 definite purpose contactor rated for 60 amps with a 3-pole configuration and a 480 volt AC coil.This contactor features double quick connect terminals, a durable metal base plate for easy mounting, and is designed for HVAC, pump, and general motor control applications. It offers quiet operation, weld-resistant silver cadmium oxide contacts, and reinforced thermalset polyester housing. The 42EF35AH supports DIN rail mounting and provides visual contact position indication.
- Amperage: 60 Amps
- Voltage: 480 Volt AC Coil
- Poles: 3
- Mounting Type: Metal Base Plate (optional DIN rail compatible)
- Class: 42 Definite Purpose Contactor
- Terminals: Double Quick Connect
- Contact Material: Silver Cadmium Oxide
- Housing: Reinforced Thermalset Polyester
- Applications: HVAC, Pumps, Refrigeration, Conveyors
- Quiet Operation
- Visual Contact Position Indication
- Certifications: UL Listed (implied by Class 42 standard)
Specifications
- Part Number: 42EF35AH
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 42
- Voltage : 600
- Amperage : 60
- Poles : 3
- Coil Voltage Maximum : 480
Product Data
- UPC : 783087154612
- Country of Origin : China
- Dimensions : 3.937 x 2.756 x 2.362 inch
- Weight : 1.587
