Description
42DF35AF
42DF35AF is a Furnas 50 Amp 3-pole definite purpose contactor with a 120V coil and metal base mounting designed for reliable motor control applications.This contactor features a 50 Amp inductive current rating, 3 normally open poles, and a coil voltage of 110/120 VAC at 50/60 Hz. It includes double quick connect terminals and a durable metal base mount, suitable for HVAC, pump, and industrial motor control. The Class 42 series contactor offers compact size, quiet operation, weld-resistant silver cadmium oxide contacts, and optional DIN rail mounting. It is commonly used in air conditioning, heating, refrigeration, conveyors, and other motor control applications.
- Amperage: 50 Amps
- Voltage: 110/120 VAC Coil
- Number of Poles: 3 (3NO)
- Mounting Type: Metal Base Mount (optional DIN rail)
- Series/Frame: Class 42 Definite Purpose Contactor
- Terminals: Double Quick Connect
- Application: HVAC, Pumps, Refrigeration, Conveyors
- Contact Material: Silver Cadmium Oxide
- Coil Frequency: 50/60 Hz
- Enclosure: Open
- Weight: Approximately 1.59 lbs
Specifications
- Part Number: 42DF35AF
- Manufacturer : Furnas
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 42
- Type : 42DF
- Voltage : 600
- Amperage : 50
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 120
Product Data
- UPC : 783087145115
- GTIN : 00783087000000
- Country of Origin : China
- Dimensions : 3.937 x 3.15 x 2.756 inch
- Weight : 1.587
