3VA6580-7JQ32-2AA0 - Siemens 800A 600V 3 Pole Molded Case Circuit Breaker 100kA AIC Bolt-On

3VA6580-7JQ32-2AA0

3VA6580-7JQ32-2AA0 is a Siemens 3 pole molded case circuit breaker rated for 800 amps and 600 volts with a 100kA interrupting rating at 480V and bolt-on mounting.

This Siemens 3VA series breaker features thermal magnetic trip units, bolt-on connections, and is designed for reliable protection in industrial and commercial power distribution applications. It supports 3 poles with a frame designed for 600V AC systems and offers a high interrupt rating of 100kA at 480V, ensuring robust fault current interruption capability.

• Amperage: 800A
• Voltage Rating: 600V AC
• Poles: 3
• Interrupting Rating: 100kA at 480V
• Mounting Type: Bolt-On
• Series/Frame: Siemens 3VA
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed, IEC Compliant (typical for Siemens 3VA series)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Does Not Include Lugs
Suitable for Reverse Fed Applications

Specifications

• Part Number: 3VA6580-7JQ32-2AA0
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : 3VA
• Voltage : 690V AC
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LSIG
• Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
• Protection : Thermal Magnetic
• Trip Type : ETU560

Product Data

• UPC : 80476698145
• GTIN : 00804766981456
• Country of Origin : Mexico
• Dimensions : 14.173 x 9.843 x 7.087 inch
• Weight : 29.321 lb
• Standards : UL Listed
• Certification : UL Listed
