Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
3VA5460-5EC61-0AA0
3VA5460-5EC61-0AA0 is a Siemens 3VA5 series 2-pole molded case circuit breaker rated at 600A with thermal-magnetic trip.
This bolt-on breaker offers line protection with TM230 trip unit (long time and instantaneous functions), FTAM fixed thermal-magnetic adjustment, and In=600A overload protection Ir=600A. It features load side lug terminals, suitability for reverse fed applications, and non-interchangeable trip. Built on the 3VA54 600A frame for robust performance in residential, commercial, and industrial settings.
Key Specifications
- Manufacturer: Siemens
- Part Number: 3VA5460-5EC61-0AA0
- Series/Frame: 3VA5 / 3VA54
- Amperage: 600A
- Poles: 2
- Voltage: 600VAC / 250VDC
- Mounting Type: Bolt-On
- Trip Unit: Thermal-Magnetic (TM230, FTAM)
- Interrupt Rating: 35kA @ 480V, 18kA @ 600V, 85kA @ 240V
- Protection: Line Protection
- Approval: UL
Specifications
- Part Number: 3VA5460-5EC61-0AA0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : 3VA
- Amperage : 600
- Poles : 2
- AIC rating : 35kA@480V
- Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
- Protection : Thermal Magnetic
- Compatible Frames : 3VA54
Product Data
- UPC : 80476679286
- GTIN : 00804766792861
- Weight : 23
- Standards : UL Listed
- Certification : UL Listed
