Product Info
- Manufacturer:Siemens
- Sub-Category:Overload Relay
Description
3UB8113-4BB2
3UB8113-4BB2 is a Siemens ESP200 series solid state overload relay designed for motor protection with an amperage range of 0.75 to 3.4 amps.This 3-phase overload relay features a Class 5...30 trip unit, direct mounting capability, and screw terminal connections for both main and auxiliary circuits.
- Key Specifications
- Amperage Rating: 0.75 to 3.4 A
- Phase: 3-Phase
- Mounting Type: Direct Mount / Stand-Alone
- Contact Form: 1NO-1NC
- Trip Class: 5...30, switchable
- Terminal Type: Screw Terminals (Main and Auxiliary)
- Operating Temperature Range: -25 to 65 °C
- Dimensions: Approx. 4.61 x 4.38 x 3.98 inches
- Series: ESP200
- Application: Motor Protection
Specifications
- Part Number: 3UB8113-4BB2
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Overload Relay
- Section : Solid State
- Family : ESP200
- Type : ESP200
- Temp Rating : -13-158 ¡F (-25-70 ¡C)
- Amperage Maximum : 3.4
- Amperage Minimum : .75
Product Data
- UPC : 662643897197
- GTIN : 00662643897197
- Dimensions : 4.37" X 4.61" X 3.98"
- Weight : 0.6 lb
- Temp Rating : -13-158 ¡F (-25-70 ¡C)
