3RV20111GA15 - Siemens 6.3A 690V 1-Pole Motor Protection Circuit Breaker S00 Frame Class 10 A-Release

3RV20111GA15

3RV20111GA15 is a Siemens motor protection circuit breaker designed for reliable motor control and protection.This circuit breaker features a 6.3 ampere current rating with a voltage rating of up to 690 volts AC. It has a single pole configuration and belongs to the S00 frame size series. The device includes a Class 10 thermal trip unit for motor protection and screw terminal mounting suitable for DIN rail installation. It offers short-circuit protection with a magnetic trip design and auxiliary contacts rated 1NO-1NC. The compact dimensions are approximately 97 mm height, 45 mm width, and 97 mm depth. It is certified for industrial use and supports side-by-side mounting with minimal spacing requirements.

Key Specifications
• Amperage: 6.3 A (adjustable 4.5 to 6.3 A)
• Voltage Rating: 690 V AC
• Poles: 1
• Mounting Type: Screw and snap-on DIN rail (35 mm)
• Interrupt Rating: Standard switching capacity, 82 A N-release
• Series/Frame: S00
• Trip Unit: Class 10 thermal-magnetic
• Auxiliary Contacts: 1NO-1NC
• Dimensions: 97 mm H x 45 mm W x 97 mm D
• Certifications: Industrial standards compliant
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: 3RV20111GA15
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sirius
• Type : 3RV
• Voltage : 690 690



Product Data

• UPC : 662643924039
• Country of Origin : Germany
• Dimensions : 4.016 x 1.929 x 4.016 inch
• Weight : 0.802
