Product Info
- Manufacturer:Siemens
- Sub-Category:Overload Relay
Description
3RU1116-1HB0
3RU1116-1HB0 is a Siemens Sirius S00 frame thermal overload relay designed for reliable motor protection in three-phase applications. This IEC-rated device features adjustable current settings from 5.5 to 8.0 amps, Class 10 tripping, and phase loss sensitivity for enhanced safety. It mounts directly to compatible contactors and includes screw terminals for both main and auxiliary circuits. The relay is built for vertical mounting with flexible orientation options. Key Specifications
- Part Number: 3RU1116-1HB0
- Manufacturer: Siemens
- Series/Frame: Sirius S00
- Rated Current: 5.5 to 8.0 A
- Mounting Type: Contactor Mounting
- Terminal Type: Screw Terminal
- Tripping Class: Class 10
- Phase Loss Sensitivity: Yes
- Auxiliary Contacts: 1NO + 1NC
- Mounting Orientation: Vertical, +/-135° rotatable, +/-45° tiltable
- Application: Three-phase motor protection
- Standards: IEC
Specifications
- Part Number: 3RU1116-1HB0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Overload Relay
- Relay Style : Thermal
- Amperage Maximum : 8
- Amperage Minimum : 5,5
Product Data
- Weight : 0.33
