Product Info
- Manufacturer:Siemens
- Sub-Category:Overload Relay
Description
3RU1116-1EB0
3RU1116-1EB0 is a Siemens thermal magnetic overload relay designed for motor protection with adjustable current settings from 2.8 to 4.0 amps.3RU1116-1EB0 features Class 10 tripping characteristics, phase loss sensitivity, and mounts directly to Siemens 3RT size S00 contactors. It includes automatic and manual reset options and uses screw terminals for both main and auxiliary circuits. The relay is suitable for three-phase motor protection and requires separate short-circuit protection.
- Adjustable current range: 2.8 to 4.0 Amps
- Class 10 tripping characteristic
- Size S00 frame
- 3-pole thermal overload relay
- Mounts on Siemens 3RT1015, 3RT1016, 3RT1017 contactors
- Main and auxiliary circuit screw terminals
- Automatic and manual reset
- Phase loss sensitivity
- IEC rated for motor protection
- Weight approx. 0.34 lb
Specifications
- Part Number: 3RU1116-1EB0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Overload Relay
- Family : Sirius
- Type : 3RU11
- Relay Style : Thermal
- Amperage Maximum : 4
- Amperage Minimum : 2.8
Product Data
- UPC : 075455441161
- GTIN : 00754554411613
- Weight : 0.341
