3RT20261AP60 - Siemens SIRIUS 3RT2 25A 3-Pole 220/240VAC Power Contactor, DIN Rail Mount, UL/CSA/CE Certified

3RT20261AP60

3RT20261AP60 is a Siemens SIRIUS 3RT2 series 3-pole power contactor designed for reliable motor control applications.

This non-reversing contactor features a 25A current rating at 400V (AC-3), with a 220/240VAC coil, and is suitable for 3-phase systems. It offers robust performance with a high switching frequency and is certified for global markets. The unit is designed for vertical DIN rail mounting and includes screw terminal connections for easy installation.

Key Specifications
• Amperage: 25A (AC-3)
• Voltage: 400V (AC-3), 220/240VAC coil
• Poles: 3
• Mounting Type: DIN Rail (vertical)
• Interrupt Rating: Not specified in available data
• Series/Frame: SIRIUS 3RT2
• Trip Unit: Not applicable (contactor, not circuit breaker)
• Certifications: UL, CSA, CE, EAC, CCC, C-TICK
• Contact Configuration: 3NO (main contacts)
• Connection Type: Screw terminal
• Operating Temperature: -25°C to +60°C
• Switching Frequency: Up to 5,000 operations/hour (AC)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3RT20261AP60
• Manufacturer : Siemens
• Brand : Siemens
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Draw-Out
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Protection : Solid State

Product Data

• UPC : 066264391375
• GTIN : 00662643913750
• Country of Origin : Germany
• Dimensions : 3.622 x 2.126 x 4.154 inch
• Weight : 0.915 lb
• Certification : REACH Art 33, WEEE (2012/19/EU)
