Description
3RT1035-3AG16
3RT1035-3AG16 is a Siemens Sirius size S2 three-pole IEC power contactor designed for reliable motor control and switching applications. This contactor delivers 40 amperes at AC-3 duty with 400V rated voltage, making it suitable for industrial motor control up to 30 horsepower at 460 volts in three-phase applications. The unit features screw terminals and mounts directly on standard 35mm DIN rail for flexible installation in control panels and motor starter assemblies. Optional auxiliary contact blocks and thermal or solid-state overload relays can be added to provide comprehensive motor protection and signaling capabilities.
- Rated 40 A AC-3 at 400 V
- Three-pole configuration for three-phase motor control
- Size S2 Siemens Sirius contactor
- IEC and UL rated for industrial applications
- DIN rail mountable with screw terminals
- Compatible with 3RH1921 auxiliary contact blocks
- Supports 3RU1136 thermal or 3RB2036 solid-state overload relays
- Thermal short-time current limited to 400 A
- Operating frequency up to 1000 cycles per hour at AC-3
- Power loss 2.6 W at AC-3 400V rated current
Specifications
- Part Number: 3RT1035-3AG16
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Sirius
- Type : 3RT10
- Voltage : 600
- Amperage : 40
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 110
- Coil Voltage Minimum : 110
Product Data
- Weight : 3
