Description
3RT1026-3BW44
3RT1026-3BW44 is a Siemens 3-pole motor contactor designed for reliable motor control applications with a 48V DC coil.
This contactor features a Size S0 frame with screw terminal connections and is rated for 25 amps at AC-3 utilization category, supporting up to 11 kW (approximately 15 HP) at 400 volts. It includes 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts, suitable for control circuit integration. The device is intended for use in industrial motor control circuits conforming to IEC standards.
- Key Specifications
- Amperage: 25 A (AC-3)
- Voltage Rating: 400 V AC
- Coil Voltage: 48 V DC
- Poles: 3
- Frame Size: S0
- Auxiliary Contacts: 2 NO + 2 NC
- Connection Type: Screw terminals
- Power Rating: 11 kW at 400 V
- Part Number: 3RT1026-3BW44
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Sirius
- Type : 3RT10
- Voltage : 600
- Amperage : 25
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 48
- Weight : 1
