Description
3RT1016-2BW42
3RT1016-2BW42 is a Siemens SIRIUS power contactor designed for AC-3 motor control applications with a rated current of 9 A at 400 V and 4 kW capacity. This 3-pole contactor features a 48 V DC coil voltage and is equipped with one normally closed auxiliary contact for reliable circuit control and protection. The contactor utilizes spring-type terminals for secure connections and mounts directly onto a standard 35 mm DIN EN 50022 mounting rail in Size S00 frame configuration. It is suitable for both screw and snap-on mounting applications, providing flexibility in industrial control panel installations. The unit maintains operational stability across a control supply voltage factor range of 0.85 to 1.1, ensuring consistent performance even with minor voltage fluctuations. Short-circuit protection is supported through gL/gG fuses rated at 20 A for the main circuit and 10 A for the auxiliary circuit.
- Rated Current: 9 A at AC-3 400 V
- Power Rating: 4 kW at 400 V
- Coil Voltage: 48 V DC
- Poles: 3-pole
- Auxiliary Contacts: 1 NC (Normally Closed)
- Frame Size: S00
- Terminal Type: Spring-type
- Mounting: 35 mm DIN EN 50022 rail
- Control Supply Voltage Factor: 0.85 to 1.1
- Closing Power: 3.3 W
- Holding Power: 3.3 W
Specifications
- Part Number: 3RT1016-2BW42
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Sirius
- Type : 3RT10
- Voltage : 600
- Amperage : 9
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 48
Product Data
- Weight : 5
