Product Info
- Manufacturer:Siemens
- Sub-Category:Contactors
Description
3RH29111HA21
3RH29111HA21 is a Siemens auxiliary switch block designed for use with 3RT2 and 3RH series contactors, featuring 2 normally open (NO) and 1 normally closed (NC) contacts with screw terminal connections. This front-mount auxiliary switch block provides reliable switching for industrial control applications, supporting up to 10 A at 24/230 VAC and 10 A at 24 VDC. It is rated for 10,000,000 mechanical cycles and 200,000 electrical cycles, ensuring long service life and dependable performance.
- Manufacturer: Siemens
- Part Number: 3RH29111HA21
- Accessory Type: Auxiliary Switch Block
- Contacts: 2NO + 1NC
- Mounting: Front Mount, Screw Terminal
- Rated Current: 10 A at 24/230 VAC, 10 A at 24 VDC, 3 A at 110 VDC, 1 A at 220 VDC
- Electrical Life: 200,000 cycles
- Mechanical Life: 10,000,000 cycles
- For Use With: 3RT2, 3RH Series Contactors
- Conforms to: IEC 60947-5-1
- Dimensions: 37.5 mm H x 36 mm W x 43.7 mm D
- Weight: 0.11 lb
Specifications
- Part Number: 3RH29111HA21
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactors
- Section : Electrical contacts
- Voltage : 24/230 24/230 /24/110/220 DC
Product Data
- UPC : 662643910100
- GTIN : 00662643910100
- Dimensions : 37.5 mm H x 36 mm W x 43.7 mm D
- Weight : 0.115 lb
