Product Info
- Manufacturer:Siemens
- Sub-Category:Control Relay
Description
3RH21221AF00
3RH21221AF00 is a Siemens auxiliary contact relay designed for motor control applications with a 10 ampere current rating and 110V AC coil voltage.3RH21221AF00 features 2 normally open (NO) and 2 normally closed (NC) contacts, suitable for integration with Siemens SIRIUS contactors. It supports AC-15 utilization category with a contact rating of 10A at 240V AC and insulation voltage up to 690V, ensuring reliable switching performance. The relay is DIN-rail mountable and compact with dimensions approximately 57.5 mm high, 45 mm wide, and 73 mm deep. It is manufactured in Germany and meets industrial standards for motor control auxiliary devices.
- Key Specifications
- Current Rating: 10 Amps AC-15
- Coil Voltage: 110V AC
- Contact Configuration: 2NO + 2NC
- Contact Ratings: 10A @ 240V AC, 1A @ 690V AC
- Insulation Voltage: 690V AC
- Mounting Type: DIN Rail
- Dimensions: 57.5 mm H x 45 mm W x 73 mm D
- Series/Frame: Siemens SIRIUS Auxiliary Relay
- Country of Origin: Germany
Specifications
- Part Number: 3RH21221AF00
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Control Relay
Product Data
- UPC : 662643903331
- Country of Origin : Germany
- Dimensions : 2.421 x 1.969 x 3.051 inch
- Weight : 0.514 lb
- Certification : RoHS Compliant, WEEE (2012/19/EU)
