3RH19211FE22 - Siemens Auxiliary Switch 1 NO + 1 NC, Solid-State Compatible, Size S0-S3, 690V AC

3RH19211FE22

3RH19211FE22 is a Siemens auxiliary switch designed to enhance motor contactor functionality with solid-state compatibility and reliable switching performance.

This auxiliary switch features 1 normally open (NO) and 1 normally closed (NC) contact, encapsulated and suitable for sizes S0 through S3. It supports a rated insulation voltage of 690 V AC and surge voltage resistance of 6 kV. The device is front-mounted with snap-on installation and offers a mechanical service life of up to 10 million switching cycles. It is rated for an operational current of 0.3 A at 24 V and 60 V DC (DC-13). The switch meets EN 50005 standards and provides mirror contact functionality according to IEC 60947-4-1.

• Type: Auxiliary switch, solid-state compatible
• Contacts: 1 NO + 1 NC (encapsulated)
• Size compatibility: S0 to S3
• Rated insulation voltage: 690 V AC
• Surge voltage resistance: 6 kV
• Operating current DC-13: 0.3 A at 24 V and 60 V
• Mounting: Snap-on, front-side
• Mechanical service life: 10,000,000 switching cycles
• Protection class: IP20 (front)
• Standards: EN 50005, IEC 60947-4-1 mirror contact

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3RH19211FE22
• Brand : Siemens

Product Data

• Weight : 0.141 lb
