2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Siemens
- Sub-Category:Motor Starter
Description
3RA1110-1GD15-1BB4
3RA1110-1GD15-1BB4 is a Siemens fuseless direct-on-line load feeder for motor control applications.This Siemens 3RA11 series load feeder provides direct starting capability without fuses, rated for AC 400 V operation in size S00 with current range 4.5...6.3 A. It features 24 V DC control supply with 1 normally open auxiliary contact and screw terminal connection on 60 mm busbar adapter, suitable for non-reversing motor starters.
- Part Number: 3RA1110-1GD15-1BB4
- Manufacturer: Siemens
- Type: Fuseless direct-on-line load feeder
- Frame Size: S00
- Current Rating: 4.5...6.3 A
- Voltage Rating: AC 400 V
- Control Voltage: DC 24 V
- Auxiliary Contacts: 1 NO (contactor)
- Mounting: Screw terminal on 60 mm busbar adapter
- Series: 3RA11
Specifications
- Part Number: 3RA1110-1GD15-1BB4
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Motor Starter
- Family : Sirius
- Type : 3RA
- Voltage : 600
- Amperage : 6.3
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 24
- Coil Voltage Minimum : 24
- Nema Rating : 0
Product Data
- Weight : 5
