Product Info
- Manufacturer:American/Federal Pacific
- Sub-Category:Fuse Block
Description
32033T
32033T is a 3-pole Class T fuse block designed for reliable electrical protection in power distribution systems.
This fuse block supports 200 amperes and 300 volts AC, featuring a clip-in fuse installation method for secure mounting. It is constructed with phenolic material suitable for wire sizes from 6 AWG to 350 kcmil (aluminum/copper). The device has a short circuit current rating (SCCR) of 200 kA and a torque rating of 275 lb-in. It is UL and CSA approved, ensuring compliance with industry safety standards.
- Key Specifications
- Amperage: 200A
- Voltage: 300V AC / 160V DC
- Number of Poles: 3
- Fuse Type/Class: Class T
- Fuse Installation Method: Clip-in
- Short Circuit Current Rating (SCCR): 200 kA
- Material: Phenolic
- Wire Size Range: 6 AWG to 350 kcmil (Aluminum/Copper)
- Torque Rating: 275 lb-in
- Certifications: UL, CSA
- Part Number: 32033T
- Manufacturer : American/Federal Pacific
- Brand : American/Federal Pacific
- Category : Fuse
- Item Subcategory : Fuse Block
- Family : Amp-Trap
- Type : T
- Voltage : 300
- Amperage : 200
- Temp Rating : -13–158 °F (-25–70 °C)
- Mounting : Box
- UPC : 78200167537
- GTIN : 00782001675370
- Country of Origin : Mexico
- Dimensions : 6 in x 6 in x 2.61 in
- Weight : 5
- Temp Rating : -13–158 °F (-25–70 °C)
- Certification : CSA Certified, UL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
