Description
2ACLS-6R
2ACLS-6R is a Eaton Bussmann series ACLS Class R single barrel fuse designed for medium voltage motor circuit protection.
This fuse features a 170 ampere rating with a nominal voltage of 2.4 kV and a maximum design voltage of 2.54 kV. It has a high interrupting rating of 50,000 amperes symmetrical (50 kAIC) to safely clear motor start and overload conditions. The 2ACLS-6R fuse uses ferrule and bolt-on construction for secure mounting and reliable operation in industrial applications.
- Key Specifications
- Amperage: 170A
- Voltage Rating: 2.4 kV nominal, 2.54 kV max design
- Interrupt Rating: 50 kA Symmetrical
- Fuse Type: Single Barrel ACLS
- Class: R
- Series: Bussmann 2ACLS
- Mounting: Ferrule and bolt-on construction
- Application: Motor circuit protection
- Manufacturer: Eaton
- Part Number: 2ACLS-6R
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : CLS
- Type : ACLS
- Voltage : 2540
- Amperage : 170
- AIC rating : [email protected]
- Diameter : 3
- Class Rating : R
- Barrels : 1
- UPC : 786670220916
- GTIN : 00786670220916
- Country of Origin : Canada
- Dimensions : 10.8 in x 4.2 in x 3 in (Length/Depth x Height x Width)
- Weight : 5.9
- Certification : ,IEEE Std. C37.41
