Product Info
- Manufacturer:Littelfuse
- Sub-Category:Medium Voltage
Description
23012R1C8.25
23012R1C8.25 is an R-Rated medium voltage fuse designed to provide short-circuit protection for medium voltage motors, motor controllers, and associated circuitry. This cartridge-style fuse delivers reliable overcurrent protection in demanding industrial applications requiring medium voltage distribution. Key Specifications
- Amperage Rating: 230 Amps continuous
- Voltage Rating: 8.25 kVAC
- Interrupt Rating: 80 kA at 8.25 kVAC
- Fuse Type: R-Rated
- Fuse Size/Group: 12R
- Termination Style: Cartridge (Non-Standard)
- Protection Type: Medium Voltage Fuse
- Physical Dimensions: 15.875 inches length, 3 inch diameter
Specifications
- Part Number: 23012R1C8.25
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Medium Voltage
- Family : Powr-Gard
- Type : R Rated
- Voltage : 8250
- Amperage : 230
- AIC rating : [email protected]
- Diameter : 3
- Class Rating : R
- Barrels : 1
- Clip Center : 12
Product Data
- UPC : 079458042085
- GTIN : 00079458042085
- Weight : 9
