2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Littelfuse
- Sub-Category:Medium Voltage Fuse
Description
23012R1C5.5
23012R1C5.5 is a Littelfuse R-rated medium voltage cartridge fuse designed for motor protection and associated circuitry.23012R1C5.5 features a 230 ampere rating with a voltage rating of 5.5 kVAC and an interrupting rating of 80,000 amperes asymmetrical at 5.5 kVAC. It is a single-pole fuse with a 12R fuse size and a cartridge mounting style, suitable for medium voltage applications requiring reliable short-circuit protection.
- Amperage: 230 A
- Voltage Rating: 5.5 kVAC
- Interrupting Rating: 80,000 A at 5.5 kVAC
- Fuse Size / Group: 12R
- Poles: 1
- Mounting Type: Cartridge
- Fuse Type: R-Rated Medium Voltage Fuse
Specifications
- Part Number: 23012R1C5.5
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : R Rated
- Type : R Rated
- Voltage : 5500
- Amperage : 230
- AIC rating : [email protected]
- Diameter : 3
- Class Rating : R
- Barrels : 1
- Clip Center : 12
Product Data
- UPC : 07945804172
- GTIN : 00079458041729
- Weight : 9
