2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Siemens
- Sub-Category:Motor Starter
Description
22FUF32AA
22FUF32AA is a Siemens 45 Amp, 600 Volt, 3 Pole motor starter designed for 3 phase AC motors with a 220V coil.22FUF32AA is a Class 22 full voltage heavy duty motor starter suitable for open type mounting. It supports motor power up to 10 HP and operates at 60 Hz frequency with an operating temperature range from -4 to 104 degrees Fahrenheit. This starter is engineered for reliable motor control in industrial applications.
- Key Specifications
- Amperage: 45 Amp
- Voltage: 600 Volt
- Poles: 3 Pole
- Phase: 3 Phase
- Coil Voltage: 220 Volt
- Motor Power: 10 HP
- Type: Class 22 Full Voltage Heavy Duty
- Mounting: Open Type
- Frequency: 60 Hz
- Operating Temperature: -4 to 104 °F
- Dimensions: 8.94 in H x 10.5 in W x 4.17 in D
Specifications
- Part Number: 22FUF32AA
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Motor Starter
- Voltage : 600
- Amperage : 45
- Phase : 3
- Poles : 3
- AIC rating : 100kA@480V
- Connection : Bolt-On
- Functions : LSI - Long-Time, Short-Time and Instantaneous
- Coil Voltage Maximum : 240
- Coil Voltage Minimum : 220
- Nema Rating : 2
- Protection : Solid State
Product Data
- UPC : 783087967472
- GTIN : 00783088000000
- Country of Origin : United States
- Dimensions : 10.5 in x 8.94 in
- Weight : 7.998
- Certification : CSA 22.2 No.14, NEMA ICS 2, UL 508
