2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Bulldog
- Sub-Category:Fuse Block
Description
20318
20318 is a Bulldog 3-pole fuse block designed for 30 amp, 250 volt applications with Class H fuse compatibility.This fuse block features a direct screw mount installation and is suitable for use with UL Class H and K fuses. It supports wire sizes from 14 to 10 AWG and has a spring-reinforced, screw-type connection for copper conductors. The device is UL listed and CSA certified, ensuring compliance with industry safety standards. It has a short circuit interrupt rating of 10 kA and dimensions of approximately 3 inches by 3 inches by 1.38 inches.
- Key Specifications
- Amperage: 30 A
- Voltage: 250 V AC/VDC
- Poles: 3
- Fuse Class: H (also compatible with K)
- Mounting Type: Direct screw mount
- Wire Size: 14 to 10 AWG copper
- Interrupt Rating: 10 kA
- Connection Type: Spring reinforced screw
- Certifications: UL Listed, CSA Certified
- Dimensions: 3 in x 3 in x 1.38 in
- Part Number: 20318
- Manufacturer : Bulldog
- Brand : Bulldog
- Category : Fuse
- Item Subcategory : Fuse Block
- Type : 203
- Voltage : 250
- Amperage : 30
- UPC : 782001759797
- Country of Origin : Mexico
- Dimensions : 3 in x 3 in x 1.38 in
- Weight : 50
- Certification : CSA Certified, UL Listed
