Product Info
- Manufacturer:Mersen
- Sub-Category:Fuse Block
Description
20316R
20316R is a Mersen 30A, 250V, 1-pole Class R fuse block designed for reliable circuit protection in demanding applications.
This barrier-type fuse block features a molded glass-filled polycarbonate construction, spring-reinforced contacts, and screw-type terminals for 10-14 AWG copper wire. It is engineered for use with UL Class RK1 and RK5 fuses, offering high interrupting capacity and robust electrical performance.
-
Key Specifications
- Amperage: 30A
- Voltage: 250V AC/DC
- Poles: 1
- Mounting Type: Screw (Cu #10-14)
- Interrupt Rating: 200,000 AIC RMS
- Series/Frame: Class R (RK1/RK5)
- Trip Unit: Not applicable (fuse block only)
- Certifications: UL listed (IZLT, E52283), UL recognized component (IZLT2, E52283), CSA certified (Class 6225, File 32169)
- Material: Molded glass-filled polycarbonate
- Wire Size: 14 to 10 AWG (copper)
- Spring reinforced contacts
- Meets UL 4248 requirements
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 20316R
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Fuse Block
- Type : 203
- Voltage : 250
- Amperage : 30
Product Data
- UPC : 78200175030
- GTIN : 00782001750305
- Country of Origin : Mexico
- Dimensions : 1-1/4 in x 3 in x 1.38 in
- Weight : 0.14
