1KES100T - Cutler Hammer 100 Amp Circuit Breaker Rating Plug Series C

1KES100T

1KES100T is a 100 Amp circuit breaker rating plug from Cutler Hammer, designed for use with Series C circuit breakers. It provides reliable current rating for compatible breaker frames.This rating plug is compatible with multiple Series C frames including KD, DK, KDB, HKD, HKDB, KDC, CKD, CHKD, KW, HKW, and KWC. It supports up to 600V AC and is used to set the trip rating on adjustable trip units such as the Digitrip RMS 310. The plug ensures proper coordination and protection in electrical distribution systems.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 100 Amp
• Voltage: 600V AC
• Compatible Series: C (KD, DK, KDB, HKD, HKDB, KDC, CKD, CHKD, KW, HKW, KWC)
• Frame Type: Series C
• Product Type: Rating Plug for Circuit Breakers
• Trip Unit Compatibility: Digitrip RMS 310 and similar
• Interrupt Rating: Matches Series C breakers
• Mounting Type: Plug-in rating device
• Certifications: OEM Eaton/Cutler Hammer

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 1KES100T
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Rating Plug
• Family : Series C
• Type : 1KES
• Amperage : 100
• Frame Size : 100
• Amperage Maximum : 100
• Amperage Minimum : 100
• Compatible Frames : KD,DK,KDB,HKD,HKDB,KDC,CKD,CHKD,KW,HKW,KWC
• Trip Type : DIGITRIP,RMS310,KES

Product Data

• UPC : 786679268766
• GTIN : 00786679268766
• Country of Origin : United States
• Dimensions : 2.3 in x 1.4 in x 1.5 in (Length/Depth x Height x Width)
• Weight : 0.04
• Certification : UL Listed
