- Manufacturer:Allen-Bradley
- Sub-Category:Overload Relay
Description
193-T1AB40
193-T1AB40 is an Allen-Bradley thermal overload relay designed for motor protection with an adjustable current range of 2.9 to 4.0 amps and Class 10 trip rating.This bimetallic overload relay features ambient temperature compensation, phase loss sensitivity with differential release, and both manual and automatic reset options. It mounts directly on the load side of 100-C09 to 100-C25 contactors for easy installation and reliable motor overload protection in normal duty applications.
- Adjustable current range: 2.9 to 4.0 amps
- Trip class: 10 (trips within 10 seconds)
- Bimetallic, ambient temperature compensated
- Phase loss sensitive with differential release
- Manual and automatic reset capability
- Mounts on 100-C09 to 100-C25 contactors
- Suitable for AC and DC motor protection
- Includes reset and stop buttons
- Operating temperature range: -20 to +60 °C
- Complies with IEC/EN 60947-4-1 standards
Specifications
- Part Number: 193-T1AB40
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Motor Control
- Item Subcategory : Overload Relay
- Compatible Frames : MA
Product Data
- UPC : 662074728145
- Weight : 0.26
