Product Info
- Manufacturer:Allen-Bradley
- Sub-Category:Overload Relay
Description
193-1EFMZ
193-1EFMZ is an Allen-Bradley advanced electronic overload relay designed for motor control applications with an adjustable current range of 120 to 600 amps.This overload relay features trip classes 10, 15, 20, and 30 with manual or automatic reset options. It supports 3-pole operation and pass-thru wiring for easy integration with IEC 100-C, IEC 100-E, and NEMA 300 contactors. The device includes 1 normally open (NO) and 1 normally closed (NC) contact configuration, providing reliable motor protection with adjustable trip current and RMS current sensing. It is suitable for both single- and three-phase motors and complies with industry certifications.
- Amperage range: 120-600 A
- Poles: 3
- Trip classes: 10, 15, 20, 30
- Reset type: Manual or automatic
- Contact configuration: 1 NO, 1 NC
- Mounting: Direct mount for IEC and NEMA contactors
- Pass-thru wiring capability
- Compatible with IEC 100-C, IEC 100-E, NEMA 300 frames
- Advanced electronic overload relay type
- RMS current sensing (50/60 Hz)
- Adjustable trip current
- Certifications: Industry standard motor protection certifications
Specifications
- Part Number: 193-1EFMZ
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Motor Control
- Item Subcategory : Overload Relay
Product Data
- Weight : 60
