Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
170M6309
170M6309 is a high speed square body fuse from Eaton's Bussmann series designed for reliable circuit protection.This fuse-link is rated at 550 amperes and 690 volts AC, with a size 3 body dimension of 76 x 92 x 126 mm. It features an aR operating class and is IEC certified, equipped with a type T indicator for status indication. The fuse is suitable for protecting power converters, rectifiers, and DC drives, providing fast-acting interruption to prevent damage from short circuits.
- Manufacturer: Eaton Bussmann
- Part Number: 170M6309
- Fuse Type: High Speed Square Body
- Rated Current: 550 A
- Rated Voltage: 690 V AC
- Size: 3
- Operating Class: aR
- Certification: IEC
- Type T Indicator for fuse status
- Dimensions: 76 x 92 x 126 mm
Specifications
- Part Number: 170M6309
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : 170M
- Type : 170M
- Voltage : 690
- Amperage : 550
- Connection : Bolt Down
Product Data
- UPC : 05171226374
- GTIN : 00051712263740
- Dimensions : 90 mm x 74 mm x 160 mm (Length/Depth x Height x Width)
- Weight : 3.5075
