Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
170M6251
170M6251 is a high speed square body fuse from Eaton Bussmann, designed for demanding electrical protection applications requiring fast response and high reliability.This fuse-link features a 1400A current rating and 1100V AC voltage rating, with aR class performance for superior short-circuit protection. It is built to DIN and IEC standards, includes a single indicator, and is suitable for stud mounting with bolt-down termination. The square body design ensures secure installation and optimal thermal performance.
- Part Number: 170M6251
- Manufacturer: Eaton Bussmann
- Amperage: 1400A
- Voltage Rating: 1100V AC
- Mounting Type: Stud
- Termination Style: Bolt Down
- Interrupt Rating: 3kA
- Series/Frame: Size 3
- Speed: High Speed
- Class: aR
- Standards: DIN, IEC
- Indicator: Single
Specifications
- Part Number: 170M6251
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Type : KN110
- Voltage : 1100
- Amperage : 1400
- AIC rating : 100kA@1100V
- Connection : Stud
- Class Rating : aR
Product Data
- UPC : 051712793520
- GTIN : 00051712793520
- Dimensions : 168 mm x 76 mm x 95 mm (Length/Depth x Height x Width)
- Weight : 2.0217
