170M5618 - Eaton Bussmann Series High Speed Square Body Fuse 1250A 600V Size 2 aR Class

170M5618

170M5618 is an Eaton Bussmann series high speed square body fuse designed for semiconductor and power converter protection.This fuse features a 1250 ampere rating with a 600 volt AC rating, size 2 form factor, and a high interrupt rating of 200 kAIC. It is classified as a Class aR fuse suitable for semiconductor protection applications. The fuse has a square body with center bolted tags and blade end connections, with mounting dimensions of M12 and a center-to-center connection distance of 90.9 mm. It is IEC rated and UL recognized, compliant with CE marking and RoHS standards.

Key Specifications
• Amperage Rating: 1250 A
• Voltage Rating: 600 V AC
• Fuse Size: 2
• Interrupt Rating: 200 kAIC
• Class: aR (semiconductor protection)
• Mounting Type: Center bolted tags, M12 mounting dimension
• Connection Type: Blade end x blade end
• Fuse Shape: Square body
• Compliance: IEC Rated, UL Recognized, CE Marked, RoHS Compliant
• Clearing I2T: 2400000 at 660 V
• Watt Losses: 130 W

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 170M5618
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : 170M
• Type : 170M
• Voltage : 690
• Amperage : 1250
• Class Rating : SB-2

Product Data

• UPC : 05171226190
• GTIN : 00051712261906
• Dimensions : 135 mm x 59 mm x 59 mm (Length/Depth x Height x Width)
• Weight : 0.6463
