170M4767 - Eaton Bussmann Series High Speed Square Body Fuse 700A 690V 1 Pole Stud Mount aR IEC UL

170M4767

170M4767 is an Eaton Bussmann series high speed square body fuse designed for semiconductor and general AC circuit protection.This fuse features a 700 ampere rating and a 690 volt AC rating with a single pole configuration. It has a stud mounting style with bolt down termination and a center-to-center connection distance of 115 mm. The fuse is size 1 with dimensions approximately 53 x 69 x 136 mm. It offers a breaking capacity of 200 kA and complies with IEC and UL standards. The fuse includes a single indicator for status and is classified as aR (partial range) for selective coordination.

Key Specifications
• Amperage Rating: 700 A
• Voltage Rating: 690 V AC
• Poles: 1
• Mounting Type: Stud
• Termination Style: Bolt Down
• Fuse Size: 1
• Breaking Capacity: 200 kA
• Dimensions: 53 x 69 x 136 mm
• Center-to-Center Connection: 115 mm
• Fuse Type: High Speed Square Body
• Classification: aR (Partial Range)
• Certifications: IEC, UL
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: 170M4767
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Type : SEMICONDUCTOR
• Voltage : 690
• Amperage : 700
• AIC rating : 200kA@690V
• Connection : Bolt On
• Class Rating : aR



Product Data

• UPC : 05171225985
• GTIN : 00051712259859
• Dimensions : 73 mm x 52 mm x 170 mm (Length/Depth x Height x Width)
• Weight : 1.2627
