Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
15NCLPT-1E-A
15NCLPT-1E-A is an Eaton Bussmann series medium voltage fuse designed for auxiliary transformer protection.
This 1 amp, 15.5 kV AC rated fuse features a Class E time-current characteristic with a 63 kA interrupting rating. It is a single barrel, non-indicating fuse measuring 1.6 inches in diameter and 12.9 inches in length. The fuse uses ferrule end connections and is constructed for high reliability in medium voltage applications.
- Key Specifications
- Amperage: 1 A
- Voltage Rating: 15.5 kV AC
- Interrupt Rating: 63 kAIC
- Class: E
- Fuse Size: 1.6" diameter x 12.9" length
- Poles: Single barrel (1 pole)
- Connection Type: Ferrule end x ferrule end
- Fuse Indicator: Non-indicating
- Application: Auxiliary transformer protection
- Response Time: 1E
- Construction: Cylindrical
- Certifications: IEEE Std. C37.41 Not Applicable
- Part Number: 15NCLPT-1E-A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : CLPT
- Type : NCLPT
- Voltage : 15500
- Amperage : 1
- AIC rating : [email protected]
- Connection : Ferrule
- Diameter : 1.62
- Class Rating : E
- Barrels : 1
- Clip Center : 11.5
- UPC : 051712526999
- GTIN : 00786679109458
- Country of Origin : Dominican Republic
- Dimensions : 12.9 in x 1.6 in x 1.6 in (Length/Depth x Height x Width)
- Weight : 0.001
- Certification : ,IEEE Std. C37.41
