Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
15LHLE-150E
15LHLE-150E is a medium voltage, E-Rated, HLE series fuse designed for feeder circuit, switchgear, and transformer protection applications. This fuse features a 3 inch diameter and is suitable for both indoor and outdoor installations.Engineered for reliable performance, the 15LHLE-150E offers a 15.5 kV voltage rating, 150A amperage, and a 65 kAIC interrupting rating. It is constructed for use with standard fuse clips and conforms to ANSI C37.40 dimensional standards. The fuse is UL Listed and meets Guide JEEG, File E240398.
- Manufacturer: Eaton
- Series: HLE
- Amperage: 150A
- Voltage: 15.5 kV
- Interrupting Rating: 65 kAIC
- Mounting Type: Ferrule Mounted
- Diameter: 3 inch
- Application: Feeder Circuit, Switchgear, Transformer Protection
- Indoor/Outdoor Use
- UL Listed
- Conforms to ANSI C37.40
Specifications
- Part Number: 15LHLE-150E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : LHLE
- Type : LHLE
- Voltage : 15500
- Amperage : 150
- AIC rating : [email protected]
- Diameter : 3
- Class Rating : E
- Barrels : 1
- Clip Center : 8
Product Data
- UPC : 786685494999
- GTIN : 00786685494999
- Dimensions : 20.53 in x 3 in x 3 in (Length/Depth x Height x Width)
- Weight : 0.001
