Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
15LHLE-100E
15LHLE-100E is an Eaton Bussmann series E-Rated medium voltage fuse designed for feeder circuit, switchgear, and transformer protection.
This fuse features a 125 ampere rating with a maximum voltage of 15.5 kV and a 63 kiloampere interrupting rating. It is a single barrel fuse suitable for indoor and outdoor use, providing reliable current limiting protection with cool running characteristics and visual fuse operation indication. The fuse conforms to ANSI C37.40 dimensional standards and is UL Listed under Guide JEEG, File E240398.
- Key Specifications
- Amperage: 125A
- Voltage Rating: 15.5 kV
- Interrupt Rating: 63 kA
- Fuse Type: E-Rated
- Series: Bussmann 15LHLE
- Construction: Single barrel
- Mounting Type: Ferrule mounted
- Indoor/Outdoor rated
- UL Listed (Guide JEEG, File E240398)
- Part Number: 15LHLE-100E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : LHLE
- Type : LHLE
- Voltage : 15500
- Amperage : 100
- AIC rating : [email protected]
- Diameter : 3
- Class Rating : E
- Barrels : 1
- Clip Center : 8
- UPC : 786685494937
- GTIN : 00786685494937
- Country of Origin : Dominican Republic
- Dimensions : 20.53 in x 3 in x 3 in (Length/Depth x Height x Width)
- Weight : 13
- Certification : ,IEEE Std. C37.41
