Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
15HCL-175E
15HCL-175E is a medium voltage, E-Rated clip lock double barrel fuse from Eaton designed for reliable circuit protection. This fuse is rated for 175 amps and 15.5 kV AC voltage, suitable for feeder circuits, switchgear, and transformer protection.The 15HCL-175E features a clip lock mounting type and provides a high interrupting rating of 63 kA at 15.5 kV. It conforms to ANSI C37.46 standards for E-Rated fuses, ensuring time-current performance for safe and effective operation. This fuse is intended for indoor use and is part of Eaton's Bussmann series of medium voltage fuses.
- Amperage: 175 A
- Voltage Rating: 15.5 kV AC
- Fuse Type: E-Rated Medium Voltage
- Mounting Type: Clip Lock
- Construction: Double Barrel
- Interrupting Rating: 63 kA at 15.5 kV
- Standards: ANSI C37.46
- Application: Feeder circuit, switchgear, transformer protection
- Indoor use
Specifications
- Part Number: 15HCL-175E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : HCL
- Type : HCL
- Voltage : 15500
- Amperage : 175
- AIC rating : [email protected]
- Connection : Clip Lock
- Diameter : 3
- Class Rating : E
- Barrels : 2
- Clip Center : 21.25
Product Data
- UPC : 051712526661
- GTIN : 00051712526661
- Weight : 0.001
