Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
15BHLE-175E
15BHLE-175E is an Eaton Class E BHLE medium voltage fuse rated for 175 amps and 15.5 kV voltage with a 63 kA interrupting rating.
This Eaton 15BHLE-175E fuse features a double-barrel design with a 3-inch diameter and is intended for bolt-on mounting applications. It provides current limiting protection for feeder circuits, switchgear, and transformer protection in medium voltage electrical systems. The fuse conforms to ANSI and IEEE standards and is UL listed under Guide JEEG, File E240398.
- Key Specifications
- Amperage: 175 A
- Voltage Rating: 15.5 kV
- Fuse Type: Class E BHLE
- Interrupt Rating: 63 kAIC
- Mounting Type: Bolt-On
- Construction: Double Barrel
- Diameter: 3 inches
- Standards: ANSI, IEEE, UL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 15BHLE-175E
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : HLE
- Type : BHLE
- Voltage : 15500
- Amperage : 175
- AIC rating : [email protected]
- Connection : Bolt-On
- Diameter : 3
- Class Rating : E
- Barrels : 2
- Clip Center : 21
Product Data
- UPC : 782116108213
- GTIN : 00782116108213
- Country of Origin : Dominican Republic
- Dimensions : 22.25 in x 7 in x 3 in (Length/Depth x Height x Width)
- Weight : 20
- Certification : IEEE Std. C37.41
