Description
1590Z150GY
1590Z150GY is a durable Hammond 1590Z Series die-cast aluminum circuit breaker enclosure designed for secure housing in electrical applications.1590Z150GY features a powder coat finish in light gray (RAL 7001) and meets NEMA 4, 4X, 6, 6P, 12, and 13 ratings for protection against dust, water, and corrosion. It measures 221 x 121 x 81 mm (8.7 x 4.74 x 3.18 inches) and includes a screw cover with a lift-off door design. The enclosure is suitable for mounting circuit breakers and other electrical components, with the inner panel sold separately.
- Key Specifications
- Series: 1590Z
- Material: Die-cast aluminum alloy
- Dimensions (HxWxD): 221 x 121 x 81 mm (8.7 x 4.74 x 3.18 in)
- NEMA Ratings: 4, 4X, 6, 6P, 12, 13
- Color: Light gray (RAL 7001) powder coat finish
- Door Design: Lift-off with screw cover
- Mounting: Panel mounting (inner panel sold separately)
- IP Rating: IP68
- Part Number: 1590Z150GY
- Manufacturer : Hammond
- Brand : Hammond Mfg
- Category : Circuit Breaker
- Item Subcategory : Enclosure
- UPC : 62398028016
- GTIN : 00623980280165
- Weight : 5
Additional Information
Please note that circuit breakers are not included with the enclosures and must be purchased separately.
