Product Info
- Manufacturer:Allen-Bradley
- Sub-Category:Part And Accessory
Description
1492JD3DF
1492JD3DF is a dual-level, IEC screw diode terminal block from Allen-Bradley, designed for secure, efficient motor control wiring.
This black, 1-pole terminal block features a diode in forward bias between levels, supporting wire sizes up to 2.5mm² (IEC) or #12 AWG (UL/CSA). It is engineered for reliable connections in industrial environments, with a compact footprint and robust construction.
-
Key Specifications
- Amperage: 20A (bus bar); diode current rating: 1A
- Voltage: 600V AC/DC (UL), 300V AC/DC (CSA), 400V AC/DC (IEC)
- Poles: 1
- Mounting Type: Screw connection, dual-level
- Interrupt Rating: Not specified
- Series/Frame: 1492 Series
- Trip Unit: Not applicable
- Certifications: UL, CSA, IEC
- Terminal Size: 5.1 x 69 x 55.5mm (0.20 x 2.72 x 2.19 in)
- Wire Size: #22–12 AWG (UL), #26–12 AWG (CSA), 2.5mm² (IEC)
- Diode Reverse Voltage Rating: 1000V
- Color: Black
- Country of Origin: RO
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 1492JD3DF
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Motor Control
- Item Subcategory : Part And Accessory
Product Data
- Weight : 2
