2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Allen-Bradley
- Sub-Category:Tools
Description
1492-JDG3FB
1492-JDG3FB is a three-level feed-through fuse block from Allen-Bradley designed for reliable circuit protection with a hinged-arm fuse circuit and screw connection.This terminal block features a 10 amp amperage rating with a voltage rating of 500V/600V AC/DC. It supports wire sizes from 22 to 12 AWG for the fuse circuit and feed-through circuit, with a gray housing color. The block includes a ground point and is UL, CSA, IEC, CE, and KC certified. Its compact dimensions are approximately 91.5 mm by 57.8 mm, suitable for panel mounting.
- Key Specifications
- Amperage: 10 A (Fuse Circuit), 20-25 A (Feed-Through Circuit)
- Voltage Rating: 500V/600V AC/DC
- Poles: 1 Pole
- Mounting Type: Panel Mount (Screw Connection)
- Wire Size Range: #22 to #12 AWG (Fuse and Feed-Through Circuits)
- Fuse Size: 5 x 20 mm (not supplied)
- Color: Gray
- Certifications: UL, CSA, IEC, CE, KC
- Dimensions: 91.5 mm x 57.8 mm x 8 mm
- Housing Temperature Range: -58 to +248 °F (-50 to +120 °C)
- Part Number: 1492-JDG3FB
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Circuit Breaker
- Item Subcategory : Tools
- Weight : 0.08
