1489-M2C030 - Allen-Bradley 3A 2-Pole Circuit Breaker, 480Y/277V AC, Trip Curve C, Thermal-Magnetic, DIN Rail Mount

1489-M2C030

1489-M2C030 is a 3 amp, 2-pole thermal-magnetic circuit breaker from Allen-Bradley designed for branch circuit protection with a C trip curve.This miniature circuit breaker supports a maximum voltage of 480Y/277V AC and 96V DC, with a rated interrupting capacity of 10 kA at 400/415 VAC. It features a DIN-35 rail mounting type, complies with UL 489 and IEC/EN standards, and offers reliable overload and short-circuit protection with a thermal-magnetic trip unit.

Key Specifications
• Amperage: 3 A
• Poles: 2
• Rated Voltage: 480Y/277V AC, 96V DC
• Trip Curve: C
• Interrupt Rating: 10 kA at 400/415 VAC
• Mounting Type: DIN-35 Rail
• Series/Frame: Bulletin 1489-M
• Certifications: UL 489, CSA, IEC/EN
• Electrical Service Life: 20,000 cycles
• Mechanical Service Life: 20,000 cycles
• Operating Frequency: 50/60 Hz
• IP Rating: IP40
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: 1489-M2C030
• Manufacturer : Allen-Bradley
• Brand : Allen-Bradley
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 480
• Amperage : 3
• Phase : 1
• Poles : 2
• AIC rating : 10kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• UPC : 885630619125
• Weight : 0.8
