Product Info
- Manufacturer:Allen-Bradley
- Sub-Category:Molded Case
Description
1489-M1C630
1489-M1C630 is a 63 Amp, 1-pole miniature circuit breaker from Allen-Bradley designed for reliable branch circuit protection.This thermal-magnetic circuit breaker features a Type C trip curve, suitable for inductive loads, and is rated for 277 Volt AC and 48 Volt DC operation. It supports fast breaking time, dual terminals for wiring flexibility, and reversible line/load connections. The breaker is UL 489 listed and certified to multiple standards including CSA, CE, CCC, and VDE, making it suitable for extreme ambient conditions with temperature ratings from -25 to 55 degrees Celsius. It mounts on standard DIN rails and offers a 10 kA interrupting capacity.
- Key Specifications
- Amperage: 63 A
- Voltage Rating: 277 V AC, 48 V DC
- Poles: 1
- Trip Curve: Type C
- Interrupting Capacity: 10 kA
- Mounting Type: DIN Rail
- Standards: UL 489, CSA C22.2 No. 5.1, CE, CCC, VDE
- Operating Temperature: -25 to 55 °C
- Dual Terminals for Wiring Flexibility
- Reversible Line and Load Connections
Specifications
- Part Number: 1489-M1C630
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 240
- Amperage : 63
- Phase : 1
- Poles : 1
- AIC rating : 10kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 885630619408
- Weight : 0.28 lb
