1489-M1C300 - Allen-Bradley 30A 1-Pole Miniature Circuit Breaker, Trip Curve C, UL/CSA 277V AC, DIN Rail Mount

1489-M1C300

1489-M1C300 is a 30A, 1-pole miniature circuit breaker from Allen-Bradley's Bulletin 1489-M series, designed for branch circuit protection in industrial and commercial applications. This breaker features a Trip Curve C, suitable for general-purpose loads, and is rated for up to 277V AC per UL/CSA standards. It is DIN rail mountable and offers reliable thermal-magnetic protection for sensitive equipment. The device is UL 489 listed and CSA certified, ensuring compliance with North American safety standards. Its compact design and finger-safe terminals make it ideal for panelboard and control panel installations. The 1489-M1C300 provides robust protection with a 10 kA interrupting capacity, making it suitable for a wide range of electrical environments. It is designed for easy installation and maintenance, with dual terminals to help prevent wiring errors. The breaker is RoHS compliant and fully recyclable, supporting sustainable practices in electrical installations.

• Part Number: 1489-M1C300
• Manufacturer: Allen-Bradley
• Series: Bulletin 1489-M
• Rated Current: 30A
• Number of Poles: 1
• Rated Voltage: 277V AC (UL/CSA), 230V AC (IEC/EN)
• Mounting Type: DIN Rail
• Interrupting Capacity: 10 kA
• Tripping Characteristic: Trip Curve C
• Certifications: UL 489 Listed, CSA Certified
• Standards: UL 489, CSA C22.2 No. 5.1, EN 60947-2
• RoHS Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 1489-M1C300
• Manufacturer : Allen-Bradley
• Brand : Allen-Bradley
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 277
• Amperage : 30
• Phase : 1
• Poles : 1
• AIC rating : 10kA@277V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 885630619460
• Weight : 0.31
