Product Info
- Manufacturer:Allen-Bradley
- Sub-Category:Molded Case
Description
140MT-C3E-B25
140MT-C3E-B25 is a motor protection circuit breaker from Allen-Bradley designed for reliable motor overload and short-circuit protection.This 3-pole motor protection circuit breaker features an adjustable thermal current range of 1.6 to 2.5 amps with a Class 10 trip rating. It mounts on a standard 35mm DIN rail and uses screw terminals for secure electrical connections. The breaker has a frame size C and standard magnetic trip fixed at 14 times the rated current. It supports front and side auxiliaries for signaling and is compatible with 100-C and 100-E series IEC contactors for combination motor starters. Certified to IEC 60947-2 and IEC 60947-4-1 standards, it carries UL, CE, ATEX, IECEx, and other international certifications.
- Key Specifications
- Amperage Range: 1.6 to 2.5 A adjustable
- Poles: 3
- Mounting Type: 35mm DIN rail
- Interrupt Rating: 100 kA at 400 V AC
- Frame Size: C
- Trip Unit: Adjustable thermal, fixed magnetic (Class 10)
- Terminal Type: Screw connection
- Voltage Rating: Up to 690 V AC
- Degree of Protection: IP2X
- Certifications: UL Listed, CE, ATEX, IECEx, CCC, Eurasian Economic Community, Registro Italiano Navale
Specifications
- Part Number: 140MT-C3E-B25
- Manufacturer : Allen-Bradley
- Brand : Allen-Bradley
- Category : Circuit Breaker
- Item Subcategory : Molded Case
Product Data
- UPC : 191326561860
- GTIN : 00191326561860
- Weight : 0.77 lb
